RC Audio
RC Audio TLM 1
RC Audio TLM 1
In stock
Couldn't load pickup availability
Signal processor
The TLM 1 incorporates several unique tools dedicated to controlling loudness and sub/infra frequencies. This unique tool on the market allows you to control the overall volume and bass volume in an ultra-transparent manner, without degrading audio quality.
AES3 Compatibility
The TLM1 incorporates a brand new AES3 (also known as AES/EBU) 96 kHz compatible I/O card, offering both digital and traditional analog input and output connections.
Leveliza Volume Normalization
The TLM 1 incorporates an advanced version of the proven and revolutionary LEVELIZA system for managing average loudness levels.
NOPE limiter
The TLM 1 features the new NOPE LIMITER system, designed to seamlessly control maximum loudness levels.
Basswatch Bass Control
The BASSWATCH system is integrated here to manage maximum bass and sub-bass levels.
OVERLYSER
The new OVERLYSER circuit analyzes the musical content and detects significant increases in program level so that the LEVELIZA system can adapt more quickly, while preventing LEVELIZA from being disturbed by other short peaks of loudness, such as over-amplified microphones, sound effects, etc.
Technical characteristics
- Dimensions: Standard 19-inch 1U case, 300 mm depth
- Power supply: 100-240 V AC, 47-63 Hz, maximum current 0.45 A
- Audio Connections: Balanced analog input and output via XLR per channel
- Power Connection: Standard IEC type C14 power socket
- Maximum input level: 20 V RMS (balanced) or 10 V RMS (unbalanced) before saturation
- AES3 Input/Output: Up to 96 kHz, stereo signal connection via XLR input and output
