Headphone amplifier & balanced preamplifier

The SMSL VMV P2 is a high-performance desktop preamplifier and headphone amplifier, offering generous power and highly precise sound. It is built on a carefully designed balanced architecture that delivers up to 2 x 6 W into 32 ohms or 2 x 350 mW into 600 ohms, all housed in a superb aluminium chassis that is both sturdy and elegant.

Specifications

• Balanced and unbalanced inputs
• Headphone outputs: 4.4 mm balanced, 4-pin XLR balanced, 6.35 mm unbalanced
• Line outputs: balanced and unbalanced
• Output power: 2 x 12 W (16 Ω); 2 x 6 W (32 Ω); 2 x 700 mW (300 Ω); 2 x 350 mW (600 Ω)
• Signal-to-noise ratio: 133 dB
• Dynamic range: 133 dB
• THD+N: -123 dB, 0.00006% (1 kHz, 32 Ω)
• Input impedance: 47 kΩ
• Headphone output impedance: close to 0 Ω
• Line output impedance: 44 Ω balanced; 22 Ω unbalanced
• Frequency response: 20 Hz – 100 kHz (-0.5 dB)
• Unbalanced gain: low (-9 dB), mid (0 dB), high (18 dB)
• Balanced gain: low (-3 dB), mid (6 dB), high (24 dB)
• Power consumption (EN60065): < 60 W
• Dimensions: 280 x 51 x 235.7 mm (W x H x D)
• Weight: 3.25 kg
